2-stroke power for mowing and mulching
The AS 510 ProClip 2in1 2T A is equipped with the world’s only 2-stroke engine that meets the requirements stipulated by the EU Emissions Directive 97/68/EC. The AS 2-stroke engine maintains engine lubrication regardless of position, enabling work on inclines of 40 degrees and more without the risk of engine damage. In addition, the AS 2-stroke engine is factory-equipped with an EasyStart function; the CDI digital ignition system cuts the rpms required to start in half. The 2-stroke engine’s high torque ensures that the power of the AS 510 ProClip 2in1 2T A is not interrupted. A third crankshaft bearing and friction discs on the mulching blade protect the engine in the event of unseen obstacles. A variator allows the speed to be conveniently adjusted from 2.1–4.3 km/h while in motion. Double ball-bearing front wheels and rear wheel drive provide easy handling. The front wheels’ special wedge shape minimizes impact on the grass, leading to extremely uniform cutting results. Cutting height can be adjusted from 40–90 mm via a spring-supported system. The AS 510 ProClip 2in1 2T ES A is a combination machine that allows the operator to choose between mowing and mulching. The machine is factory-equipped with an easy-to-mount mulch plate, and side discharge deflector for grass up to 50 cm high. Ideal for overgrown lawns and extended mowing intervals on natural meadows.
The specially-designed mulching blade cleanly cuts grass up to 20 cm high and simultaneously generates an airflow that whirls the cuttings in the mulching unit. The mulching blade’s three cutting edges chop and mulch the grass several times. The cuttings then sink into the turf, forming a layer of mulch that both fertilises and protects the lawn from drying out. The AS 510 ProClip 2in1 2T A saves 30% more time when compared with collection bag lawn mowers by avoiding the need to empty the collection bag as well as cost-intensive cuttings disposal. Mow or mulch: The AS 510 ProClip 2in1 2T A is factory-equipped with an easy-to-mount mulch plate and side discharge deflector. Thus grass up to 50 cm high can be mowed with side discharge.
- Engine suitable for slopes: The world's only AS 2-stroke engine with EasyStart has position-independent lubrication, ensuring safe operation even on steep slopes.
- 2in1 function: Mulch or mow with side discharge, the AS 510 2in1 can do both.
- Up to 30% time saved: No collection basket, no cuttings disposal and fertilise the lawn simultaneously.
- Blade shaft bearing arrangement protects the engine: Third crankshaft bearing and friction discs on the mulching blade ensure optimal engine protection.
- Traction drive (AS 510): Comfortable work through variable adjustable speed (variator) in conjunction with large, aggressive tread drive wheels for optimal traction.
- Stable double frame: Stable tube frame with replaceable mulching unit.
Features and Benefits
Stable mulching unit
Closed and deep mulching unit for uniform results.
Cutting height adjustment
Central spring-supported height adjustment.
Special front wheels
Double ball-bearing supported, smooth-running wheels press down very little grass.
Operating bar
Stable bar height adjustment without tools.
Warranty
At AS-Motor, we understand that professional users, municipalities, and property owners need more than just high-performance mowing technology – they need confidence in their investment. That’s why we go beyond industry norms to offer a warranty system that sets new standards in the landscaping sector.
Technical Data
| cutting width | 51 cm |
| maximum grass height "mulching" | 20 cm |
| engine manufacturer | AS-Motor |
| engine type | AS 165 ES |
| single-cylinder engine, 4-stroke / 2-stroke | No / Yes |
| work rate max. | 4,4/6,0 kW (hp) |
| rated power | 2,8/3,8 kW (hp) |
| nominal speed | 2800 rpm |
| third crankshaft beariing for engine protection | Yes |
| 100% mulching function | Yes |
| additional side discharge | Yes |
| cutting height | 40 – 90 mm |
| central cutting height adjustment | Yes |
| cutting height adjustment: levels | 6 |
| rear-wheel drive | Yes |
| Number of speeds | Vario |
| speed max. | 4,3 km/h |
| Handlebar height adjustment | Yes |
| ill quantity – fuel tank | 5 l |
| Dimension L/W/H | 139x55x100 cm |
| weight | 48 kg |
